Magnum swap?

Engine Swaps

  1. bonz buonopane

    bonz buonopane Active Member

    Messages:
    32
    Likes Received:
    0
    Joined:
    Dec 9, 2011
    Location:
    Delaware
    bought a 2001 5.9 out of a Dakota rt, hoping to swap out my tired-ass 78 318/2. Has anyone done this? What do I need?

  2. aspen77rt

    aspen77rt Well-Known Member

    Messages:
    381
    Likes Received:
    48
    Joined:
    Jul 25, 2011
    Location:
    Shelton, WA
    Last edited: Jan 16, 2016
  3. kkritsilas

    kkritsilas Well-Known Member

    Messages:
    1,726
    Likes Received:
    318
    Joined:
    Jun 21, 2012
    Location:
    Calgary, Alberta, Canada
  4. jasperjacko

    jasperjacko Well-Known Member

    Messages:
    1,460
    Likes Received:
    180
    Joined:
    Dec 4, 2011
    Make sure you check inside the intake manifold for presence of oil. If it's in there, you have much work to do before the swap. There is a steel pan on the bottom of the intake, and the gasket between ALWAYS fails. You will need to get a kit from Hughs engines that fixes this problem. The problem is that the gasket fails, sucks engine oil, carbons the valves and pistons as well as inside the engine. Said carbon accumulation can plug pick up screen. Ask me how I know...

  5. mopower76

    mopower76 New Member

    Messages:
    3
    Likes Received:
    0
    Joined:
    Feb 3, 2013
    Loose the factory intake and buy a 4bbl magnum intake off eBay...$135 shipped bolts on, works great!
    I love magnum swaps! Serpentine accessories and full roller??? No brainier! Everything else you need for the swap will bolt on from your 318. Oil pan and all! I have even swapped with a 62 y-block 318.... Oil pan, distributor and even the converter and push button Trans worked!
    As long as you are going carb it's simple as pie! Loosing that barrel intake will really un-cork that motor! Good luck and enjoy!
    Mopar to ya!

  6. kkritsilas

    kkritsilas Well-Known Member

    Messages:
    1,726
    Likes Received:
    318
    Joined:
    Jun 21, 2012
    Location:
    Calgary, Alberta, Canada
    Be sure to have the heads checked for cracks between the valves. Magnum heads are notorious for doing that. May or may not be a problem, but you won't know until you check and have them verified.

  7. aspen77rt

    aspen77rt Well-Known Member

    Messages:
    381
    Likes Received:
    48
    Joined:
    Jul 25, 2011
    Location:
    Shelton, WA
    I don't believe his la 318 oil pan will swap over.

    If those heads are cracked, talk to Hughes and get a set of EQ magnums drilled for la manifold.

    Hughes Engines

  8. barnfind

    barnfind Well-Known Member

    Messages:
    45
    Likes Received:
    3
    Joined:
    Nov 30, 2015
    Location:
    ND
    Looking forward to seeing this done.

  9. bonz buonopane

    bonz buonopane Active Member

    Messages:
    32
    Likes Received:
    0
    Joined:
    Dec 9, 2011
    Location:
    Delaware
    It's done. Will post pics when I get some good light! What a difference. Turns wheels like a champ now!
    --- Post updated ---
    Got everything together, runs great when I'm stepping on it, but at low speeds, when I push the gas lightly, it chokes out. Ideas??? I have a holley600 on her


  10. hemijoe

    hemijoe Well-Known Member

    Messages:
    85
    Likes Received:
    50
    Joined:
    Mar 19, 2014
    put in some smaller primary jets to fix the bog and increase the accelerator pump squirt
