Solid K frame bushings

Chassis, Suspension and wheels

  1. MiradaMegacab

    MiradaMegacab Well-Known Member

    Messages:
    1,718
    Likes Received:
    574
    Joined:
    Feb 27, 2011
    Location:
    Long Island NY

  2. Mikes5thAve

    Mikes5thAve Well-Known Member

    Messages:
    496
    Likes Received:
    171
    Joined:
    Mar 3, 2020
    Location:
    Canada
    I've heard it before but never had a problem. Column wise for me the hard part is always popping the shifter linkage out of its bushing.

  3. BudW

    BudW Moderator Staff Member

    Messages:
    4,579
    Likes Received:
    1275
    Joined:
    Mar 4, 2012
    Location:
    Oklahoma City
    Aye, you are correct there. That shifter rod is like superglued into that bushing and takes a lot to get 'em unseated.
    Also not an easy job to pop back into place either - but at least then you can use pliers/channellocks/etc. then.

    On a different note, that steering column to shift rod bushing/grommet is to be replaced every time it is disconnected. The part number for it is 3575333 (as of 3/1/2021, the MSRP is $5.95 (US)). I have seen those bushings in black, white, clear, green, yellow/cream and in gray.
    BudW

  4. SlantSixSullivan

    SlantSixSullivan Well-Known Member

    Messages:
    122
    Likes Received:
    24
    Joined:
    Nov 21, 2016
    Location:
    East Liverpool, OH
    Yeah, the box and underneath it could use a cleaning anyway.

  5. Oldiron440

    Oldiron440 Well-Known Member

    Messages:
    2,761
    Likes Received:
    592
    Joined:
    Apr 25, 2017
    Location:
    Iowa
    Time to replace the rag joint anyway.

    SlantSixSullivan likes this.
  6. Duke5A

    Duke5A Well-Known Member

    Messages:
    1,018
    Likes Received:
    436
    Joined:
    Apr 6, 2018
    Location:
    Michigan
    MiradaMegacab likes this.
  7. MiradaMegacab

    MiradaMegacab Well-Known Member

    Messages:
    1,718
    Likes Received:
    574
    Joined:
    Feb 27, 2011
    Location:
    Long Island NY
    Yeah, I wouldn’t kick her out of bed for eating crackers!! ;)

    Duke5A and SlantSixSullivan like this.
  8. Lightning II

    Lightning II Well-Known Member

    Messages:
    109
    Likes Received:
    32
    Joined:
    Sep 24, 2020
    Location:
    Galax, VA
    Just double-checking, but do the FFI Isolators still need the lower isolators? Or does that large washer just replace it altogether?

  9. Camtron

    Camtron Well-Known Member

    Messages:
    786
    Likes Received:
    411
    Joined:
    Apr 25, 2019
    Location:
    Here
    Large washers replace them.
    Solid isolator between the frame and K frame and the washer on the bottom of the k frame with the bolt ran through.

    SuicideRider likes this.
  10. Lightning II

    Lightning II Well-Known Member

    Messages:
    109
    Likes Received:
    32
    Joined:
    Sep 24, 2020
    Location:
    Galax, VA
    Awesome. I was actually about to DM you on Instagram about it but I posted here first.

    I’ll let y’all know how my attempt at this goes.

    SuicideRider likes this.
  11. Lightning II

    Lightning II Well-Known Member

    Messages:
    109
    Likes Received:
    32
    Joined:
    Sep 24, 2020
    Location:
    Galax, VA
    well, I'm halfway done, the front ones are set, but the rear ones are giving me a bit of trouble since the K-frame isn't lowering enough even with the bolts all the way out. And yes, I did try to do the driver's side first. I did finally break out the dremel after buying new cutoff wheels for it. I ran out of daylight since I started at like 4:30/16:30 in the afternoon. I'll get it done tomorrow morning. So far Camtron's way he went about it is pretty much working though.

  12. Duke5A

    Duke5A Well-Known Member

    Messages:
    1,018
    Likes Received:
    436
    Joined:
    Apr 6, 2018
    Location:
    Michigan
    Did you use a picker to get the weight of the motor off of the K before doing this?

    Also, if you didn't split the upper ball joints you're not going to be able to lower the K far enough to get those rear bushings out in one piece. I used a pneumatic cutoff wheel do those.

  13. Lightning II

    Lightning II Well-Known Member

    Messages:
    109
    Likes Received:
    32
    Joined:
    Sep 24, 2020
    Location:
    Galax, VA
    No, I had a brain fart and didn’t get a hoist. I need to buy one anyway. It’s supposed to rain all day today, so I’ll do that in the morning.

    and I’ve already resigned myself to using the cutoff wheels regardless.

  14. Camtron

    Camtron Well-Known Member

    Messages:
    786
    Likes Received:
    411
    Joined:
    Apr 25, 2019
    Location:
    Here
    Yea. I may have had to cut the drivers side too. Really don’t remember, I know I cut the passenger side for sure. It’s been a couple years and it was a rush weekend deal.

  15. Lightning II

    Lightning II Well-Known Member

    Messages:
    109
    Likes Received:
    32
    Joined:
    Sep 24, 2020
    Location:
    Galax, VA
    so, I got them in finally yesterday. Haven't been able to drive it since because I wanna get an alignment done first. That'll get taken care of this month.
